Specification P.3/1

Pressure type internal mixer ML 20L

======================================

Main standard:

---------

1. Mixing tank effective volume:20L

B. Rachis Double blade，wearing ring adopt special alloy material.

C. Rachis rotate speed epipodium:38/39r.p.m backshaft:32/25r.p.m

D．Electricity device 1.main motor: AC 30KW,6P,380V,50HZ

2.overturn motor: AC 1.5KW,6P,380V,50HZ

E. Lubricating system 1. lubricate rachis bearing pedestal with grease lubricate

2.Oil bath self splashing lubricate for speed cut case

F. Feeding way : Front feed intake

G. Discharge way : Tilting discharge

H. Sealing method : Mechanical presses tightly sealed

I. Temperature control : Adopt water cooling, it can automatic control temperature

J. Motor direction : When the operator facing the unloading surface stand,

motor on right side, the motor and reducer is vertically.

K. Main drive system : Drive the impetus to reduction gear box, this gear box

connect front rachis by gear coupling, front rachis drive back rachis trough bite gear.

L. Overturn motor drive system: drive the impetus to worm by coupling,

Coupling drive worm.

M. Main motor protection::When the current of main motor exceed the setting

Current, the forcing cover automatic go up, When electricity get right, forcing cover automatic go down.

ZhengDeLong Machine(KunShan)Co.,Ltd

Specification P.3/2

Pressure type internal mixer ML 20L

======================================

Explaination:

1.rachis :produced by 40Gr through precision machining and wear dispose.

Work face through chromate finish.

2.Rack : Material steel plate adopt heat treatment after welding,

It made from precision mill and bore process.

3.foundation :national standard box iron and steel plate welding made from

Process.

4.Bearing pedestal: Bearing pedestal made from cast steel through

Precision machining. bearing adopt TWB brand.

5.Bite gear :Made from FCD600,straight tooth type.

6. reducer casing :200 type reduction box hard gear surface.

2 section of deceleration, helical type

Shaft gear made from S45C forging stee

Gear made from FCD600

Box made from FCD500

7. Coupling : Hole inner gear and hole outer made of cast steel.

8.Agitator and pressuring cover: It casting of special alloy and made through process

Of precision machining and chromeplate after wear resistant treatment.

9.Machinery weight: 4500KG

10.Boundary dimension: Length 2650MM Width1850MM Height:2450MM

ZhengDeLong Machine(KunShan)Co.,Ltd

Specification P.3/3

Pressure type internal mixer ML,20L

======================================

11. Overturn system :1.5KW brake motor, worm gear operated

12.Motor 1. AC 40HP,3 phase,6P,380V,50Hz full closed squirrel cage motor

2.AC 2HP,3 phase,4P,380V,50Hz full closed squirrel cage motor.

13.Electrical cabinet:Y-▽self-motion start-up method, main electrical element

Adopt T-verter brand

14.Solenoid valve :Adopt Japan SMC, match oil water separator.

15.PLC :DELTA

16.Distribution :Sealing up ring 4 PCS, pressuring cover sealing trip 4PCS,

Special tools.

17.Public Utility

一．Electricity condition

Main motor AC 380V,50HZ,three phase

Control circuit AC 220V,50Hz,single phase

Compressed air condition 6-8KG

二．Cooling or heating method the buyer provide temperature control

Device by themselves.

18.Excluding: Foundation engineering, installation project, erect project ,pipeline

Project excluding machine, electric wire structure project.
